PRODUCTS Your Position: Home - Products - Belt Driven Air Compressor - LT Series Belt Driven Air Compressor
Model: FGP170/SL FGP250/SL FGP170/HM FGP250/HM FGP360/HM FGP480/HM
INFORMATION:
Characteristic
The Italy style V-belt air compressor adopts aluminum material for air compressor pump with Z-shaped structure design; meanwhile, the Italy style pump with dual valve plate design for providing high compression efficiency and avoiding carbon accumulation. The pump cooling system is POP!

Product Performance

Model Numbers Power Speed Air Displacement Max Pressure Tank N.W Dimensions

  KW HP R.P.M L/min C.F.M Bar Psi L Gal KG LxWxH(cm)
FGP170/SL 1.5 2.2 1100 170 6.0 10 145 30 7.9 86 113x37x65
FGP250/SL 2.2 3 1100 250 8.8 10 145 30 7.9251 102 113x37x65
FGP170/HM 4.2 5.5 1050 170 6.0 8 116 30 7.9251 86 113x37x65
FGP250/HM 4.2 5.5 1050 250 8.8 8 116 30 7.9251 102 113x37x65
FGP360/HM 4.8 6.5 1050 360 12.7 8 116 55 14.52935 73 100x41x87
FGP480/HM 9.6 13 1050 480 17.0 8 116 55 14.52935 73 100x41x87
BACK >>
